Santa Fe, New Mexico Site UHF DMR/Analog FM
Mac Pass Repeater Group WR7HLN
Contact: Tom WR7AGT [email protected]

Repeater particulars:
443.150 MHz, plus 5 MHz offset
Analog FM access: PL encode/decode 131.8 Hz
DMR admission: Color Code 1
DMR Radio ID: 310992

In the tony Camino Tres Arroyos community, 3.1 miles west of downtown Santa Fe, New Mexico, 6,785 feet above sea level.

Equipment specifics:
Hytera RD985 repeater 50 watts

Operational mode:
Dynamic Dual Mode (analog FM or DMR digital on-demand)

DMR: Brandmeister

Static talk groups:
Time Slot 1 3135 New Mexico, 8 MPRG Cluster
Time Slot 2 31301 MPRG1 Mac Pass Repeater Group

Dynamic talk groups:
Time Slot 1 All BrandMeister talk groups
Time Slot 2 PLEASE DO NOT USE TIME SLOT 2 for dynamic talk groups

Coverage includes the Greater Santa Fe Metroplex, overlapping to the south and west with Sandia Crest and La Mosca Peak.

6/24/19 On the air.

Coverage map depicting the service area of the Santa Fe UHF DMR repeater
Click on this image to view the full-size version
Santa Fe UHF DMR Coverage v2 small

Cabinet with the Hytera repeater
Santa Fe Repeater Cabinet

UHF Duplexer for the repeater
UHF Duplexer for Santa Fe

Tower and dipole array antenna for the repeater
Santa Fe Tower and Antenna 190622
